CW-AT-10G-8P-N355 aqc113c 经常不识别
Officially replied2025-12-20 03:39:29
68 Times read
3 Comments
问题: linux 系统,长时间运行,aqc113c 会掉,lspci 不显示,只显示两个 i226 网口。
测试:
拔掉电源,完全断电后,再次开机才能识别,lspci 会显示。但是运行一段时间后,aqc113c 又掉了,此时 lspci 不显示了。
再次冷启动,aqc113c 恢复了,这时,进入系统,重启几次,aqc113c 又无法识别了,lspci 没有 aqc 的信息。
最最奇怪的是,aqc113c 不插网线也出现这个问题。i226 就没有消失过。
麻了,不知道哪的问题,问经销商,他说他们不提供支持,仅支持返修。

2025-12-24 20:02:20
请尝试降级BIOS:https://drive.x86pi.cn/BIOS/5.NAS-BIOS/Twin_Lake(N150-N250-N350-i3-N355)/CW-NAS-AT-10G-8P
BIOS更新教程:https://doc.x86pi.cn/#/docs/fs/VXCQuW3XQSosL8RRJL2ixp/201
由于您未提供当前BIOS信息,推荐最佳BIOS:2025-02-27版
2025-12-24 22:39:01
Hello,
Which of the two BIOSes from 2025-02-27 is the recommended version?
Also, is it possible to update the 10gb nic or the asm1164 controller firmware to support aspm?
Thank you.
Regards,
Luciano
2025-12-26 10:38:56
dmidecode
# dmidecode 3.5
Getting SMBIOS data from sysfs.
SMBIOS 3.6.0 present.
# SMBIOS implementations newer than version 3.5.0 are not
# fully supported by this version of dmidecode.
Table at 0x75CB4000.
Handle 0x0000, DMI type 0, 26 bytes
BIOS Information
Vendor: American Megatrends International, LLC.
Version: 5.27
Release Date: 05/31/2025
Address: 0xF0000
Runtime Size: 64 kB
ROM Size: 16 MB
Characteristics:
PCI is supported
BIOS is upgradeable
BIOS shadowing is allowed
Boot from CD is supported
Selectable boot is supported
BIOS ROM is socketed
EDD is supported
Japanese floppy for NEC 9800 1.2 MB is supported (int 13h)
Japanese floppy for Toshiba 1.2 MB is supported (int 13h)
5.25"/360 kB floppy services are supported (int 13h)
5.25"/1.2 MB floppy services are supported (int 13h)
3.5"/720 kB floppy services are supported (int 13h)
3.5"/2.88 MB floppy services are supported (int 13h)
Print screen service is supported (int 5h)
Serial services are supported (int 14h)
Printer services are supported (int 17h)
CGA/mono video services are supported (int 10h)
ACPI is supported
USB legacy is supported
BIOS boot specification is supported
Targeted content distribution is supported
UEFI is supported
BIOS Revision: 5.27 感谢回复!我对比了信息,发现我的BIOS版本是 CW-AT-10G-8P(N100_N150_i3-N305_i3-N355)-2025-05-31.iso应该是这个版本的BIOS。 你推荐的CW-AT-10G-8P(N100_N150_i3-N305_i3-N355)-2025-02-27.iso版本我回来去试试。- 0Answer
